1. Height of Character :Print height range is 1mm～18mm（1,2,3,4,5,6,7,8,10,12,15,18mm）
2. Printing Distance: The distance between the spray head and printing objects should be 5-10mm
3. Automatic Printing: Date, time, lot No, Shift No, Sequence No. etc.
4. Applicable products: Display screen of mobile phone, drink lids, food package bags, medicine package, steel-plastic door & window, aluminum alloy, battery, plastic tube, steel plate, PCB, chip, woven bag, egg, brake, housing for mobile phone, carton etc.
1. spray printing precision: 200 DPI
2. spray print fonts: high-definition spray print fonts (namely printing style)
3. Chinese word stock: national standard level 1 and level 2 Chinese character library (total more than 6000), seven font (song typeface, regular script, hollow body, blackbody, cloud body, new song typeface, lattice word) for your choice, pinyin input method.
4. spray print graphics: can be sprayed all kinds of trademark design, graphic transmission from length-width ratio and length of any restriction.
5. number of rows level: A180 - F (one to two line machine), A180 - F (1 to 15 line machine)
6. character height: can be sprayed printed 1 mm ~ 18 mm word high font (1, 2, 3, 4, 5, 6, 7, 8, 10, 12, 15, 18 mm)
7. spray print distance: nozzle is about 5-10 mm from spray object
8. automatic spray printing: date, time, batch number, class and serial number, etc
9. storage information: can store 100 message, 100 pattern
10. information length: each message can be up to 200 characters
11. serial number of running water : 1-8 variable serial number
12. spray printing speed: amount to 34 m/minutes, and spray printing speed don’t change with the increase of row numbers
13 ink color: black, red, white.
14. spray print direction: nozzle can rotate; Adjustable forward, backward, vertical downward; Procedures can be adjusted up and down the reverse, turn around
15. spray printing material: metal, plastic, wood, aluminum foil, cartons and building materials, and other material surface
16. suitable products: such as mobile phone screen, beverage bottle cap, food outer packaging bags, medicine boxes, window of model steel door, aluminum alloy, battery, plastic pipe, steel plate, circuit boards, chip, woven bag, eggs, brake pads, mobile phone shell, cartons, motors, transformers, water meter inside dish, gypsum board, PCB circuit boards, explosive outer packing, etc
17. use ink: quick dry environmental printing ink or oily ink, without external air and thinner
18. external interface: USB, synchronizer, light magic eye, data line
19. Machine size: 34.7 x22x 10 cm packaging size : 28*59*44cm
20. Machine support: is adjustable 50-75 cm up and down , and adjust slightly fornt and back.
21. power supply parameters: AC 220 v
22. system power consumption: the average power consumption less than 100 w
23. operational environment: temperature 0 ℃ to 40 ℃; Humidity 40% - 70%
24. status display: spray printing, synchronizer, light magic eye normal light display
-
L type inline filling machine is a new and high technology filling equipment which consists of micro computer (PLC), programmable control, photoelectric sensing and pneumatic execution.
Full Automatic Liquid High Speed Filling Packing Machine Production Line
-
This machine is suitable for packaging liquid products with good free flow. Such as: food sauces, seasonings, liquids, emulsifiable concentrates, foliar fertilizers, etc.
Automatic Paste Packing Machine
-
This type of paste filling machine adopts photoelectric automatic control system, unique piston filling form, which can not only continuous filling, but also free filling machine.
Chili Sauce Letinous Edodes Sauce Automatic Filling Packing Machine Production Line
-
Adopted piston quantitative, mechanical and electrical, pneumatic in one, electrical and pneumatic components used well-known brands.
Fully Automatic Paste Liquid Filling Processing Line
