Features :
1. Double frequency conversion control , bag length can be set and cut in one step , saving time and films.
2. Adopt PLC & HMI programming software , easy operating and setting .
3. Self failure diagnosis , clear failure display .
4. High sensitivity photocell tracing , input cutting & sealing position digitally , extra accuracy .
5. PID control temperature independently which is more suitable for packing different materials .
6. Positioned stop function , without sticking knife or wasting film.
7. Simple driving system , reliable working , convenient maintenance.
8. All control is realized through software , easy for function adjustting , technical upgrade .
Application :
This machine is suitable for pack instant noodle , biscuit , bread , pie , snack , medicine , ice cream , chocolate , mooncake , candy , frozen food , tissue , adhesive tape , soap , commodity , hardware parts , cutlery , inflight meal , etc.
Features and Advantages :
1. Full macaronis computer controlling system, bearing plate conveying structure for the material. Safe and reliable.
2. There is no secondary pollution, healthy and safe, saving labor and resources.
3. Package length of photoelectric tracking automatic marking, design accurately and conveniently.
4. automatic replace of the products, there is no need to replace the former or shaper.
5. Roller type air emissions, full compliance with standards for packing.
6. widely applicable scope: Packaging substrate: high density polyethylene, hot sealing packaging film etc.
Applications :
Packaging soft, strip and irregular objects like towels, tissues, noodles, eggrolls, sausages, fish, ice-lollies, sugar, fresh fruits, etc.
| Item | HLKDS-250D |
| Packing capacity | 40-200bags/min |
| Thickness of package | 0.03-0.06mm |
| Width of film | Max 250mm |
| Package dimension | L：65-190mm/120-280mm W：30-110mm |
| Power supply | 220V,50/60HZ,2.4KVA |
| Power | 2.4KW |
| Machine dimension | 3770mm×1400mm×1450mm |
| Weight | 550KG |
| Remark | Equipped with air filling device |
Horizontal packing machine list :
| Item | Rand | Original place |
| Invertor | Panasonic | Japan |
| PLC | Panasonic | Japan |
| Proximity switch | OMRON | Japan |
| Photocell | Yatai | Shanghai , China |
| Motor | Yongkun | China |
| Solid relay | Schedule | Germany |
| Button | Weidemiler | Germany |
| Power | Mingwei | China |
| Temperature controller | Yatai | Shanghai,China |
| Circuit breaker | Schedule | Germany |
| Brush components | Leqing mingfeng | Zhejiang,China |
| Touchable screen | Weiview | Taiwan |
1. One tools box
2. One pcs monkey spanner
3. One pcs a screwdriver + one pcs Cross screwdriver
4. One set inner hexagon spanner
5. One pcs middle sealing belt
6. Pcs push fingers
7. One user manual
8. Two pcs end sealing heater , two pcs mid sealing heater , power line 5 meter.
-
This machine is equipped with a dual-CPU microcomputer control system, a 5-inch LCD display in Chinese or English, a humanized operation interface, automatic cursor detection and tracking, and simpler operation. Equipped with a high-precision stepping motor to ensure the accuracy of the cutting position of each packaging bag.
280 350 Model Automatic Powder Packing Machine
-
PLC control with stable reliable biaxial high accuracy output and color touch screen, bag-making, measuring, filling, printing,cutting , finished in one operation.
520 Type Automatic Powder Packing Machine
-
Applicable scope for packaging milk powder, sesame paste, strong bone powder, condiments, Ganoderma lucidum powder, granules and other items.
HL-GDF Full Automatic Powder Filling and Packing Machine
-
Suitable for quantitative filling of various bottles, cans and bags,Photoelectric induction blanking, or optional foot switch blanking,Feedback scale and indexing value can be adjusted to meet various accuracy requirements.
Semi-automatic Powder Packaging Machine
