It is suitable for compound condiments (such as spicy and spicy), natural condiments (thirteen incense), food additives, flavors and fragrances, flour, milk powder, protein powder, solid beverage, sugar, monosodium glutamate, pesticide, veterinary medicine, washing powder, enzyme preparation, feed additive, chemical industry, new building materials and other powdery (micro powder, ultrafine powder) and powder grain. Quantitative packaging and filling of mixtures.
Characteristic :
Suitable for quantitative filling of various bottles, cans and bags,Photoelectric induction blanking, or optional foot switch blanking,Feedback scale and indexing value can be adjusted to meet various accuracy requirements. The speed of filling motor can be adjusted to meet the requirements of various materials.All stainless steel material, with feeder can achieve automatic level control.
Functions:
1. Automatic error correction
2. Weight error alarm
3. Product count
| Model | HL-F4 | HL-F1 | HL-F2 | HL-F3 |
| Measurement range | 1-50g | 5-5000g | 5-5000g | 1000-5000g |
| Measurement error | 0.1-1.0g | 土1% | 土1% | 土0.5% |
| Filling speed | 0-40Times/min | 0-50Times/min | 0-70Times/min | 0-12Times/min |
| Air consumption | No | No | No | 10L/min |
| Operation interface | Electronic screen | Electronic screen | LCD touch screen | LCD touch screen |
| Control system | Single chip microcomputer control | Single chip microcomputer control | Plc control | Plc control |
| Hopper volume | 15L | 50L | 50L | 50L |
| Outline size | 60*50*160 | 80*80*196 | 80*80*196 | 80*80*196 |
| Equipment weight | 120KG | 200KG | 200KG | 200KG |
| Power supply | 220V,50HZ 300W | 380V,50HZ 900W | 380V,50HZ 1500W | 380V,50HZ 1500W |
-
L type inline filling machine is a new and high technology filling equipment which consists of micro computer (PLC), programmable control, photoelectric sensing and pneumatic execution.
Full Automatic Liquid High Speed Filling Packing Machine Production Line
-
This type of paste filling machine adopts photoelectric automatic control system, unique piston filling form, which can not only continuous filling, but also free filling machine.
Chili Sauce Letinous Edodes Sauce Automatic Filling Packing Machine Production Line
-
Adopted piston quantitative, mechanical and electrical, pneumatic in one, electrical and pneumatic components used well-known brands.
Fully Automatic Paste Liquid Filling Processing Line
-
This machine is the intelligent packaging for the development of granular materials and irregular materials. Using pneumatic gate feed or belt feeding mode, advanced frequency conversion technology.
5-50KG Granule Filling Packing Machine
